Vantage 720/920 In-Line System

Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.

The Vantage Machine is an in-line Folder/Gluer with an impressive production rate (speeds up to 30,000+ cartons per hour). The Vantage line is ideally suited for producing straight-line boxes, room key holders, table tents, sleeves, CD wallets, computer software cartons and presentation folders. An optional kit for producing auto-lock bottom boxes is available.

Through Moll’s module design, you move units in and out, allowing for quicker and easier setups. For materials requiring the extra glue penetration time and positive control after folding, you will appreciate the Moll Pressure Stacker. With adjustable height intake alignment, top and bottom full width motorized blanket belts, and adjustable pressure control, Moll’s Pressure Stacker will provide the results you expect.

Features

Module design to mix and match
Friction fed
Belt drive
Vacuum infeed belts
Etched railing for quick change overs
Ability to bump-n-turn a sheet

Industries/Consumers served

Food, beverage, cosmetic, POP, pharmaceutical, sports packaging, consumer packaging, home and office packaging, industrial packaging, commercial print, mailing, sample packets, and more!

Specifications

	Imperial	Metric
Material	Cover Stock Paper, Heavy Board	Cover Stock Paper, Heavy Board
Paper weight	70lb Cover to 28pt Stocks	140–500 g/m²
Minimum product size (WxL)	2 x 4 inches	50 x 102 mm
Maximum product size (WxL)	26×20“ or 33×20” or 40×20	762x508mm or 914x508mm or 1016×508 mm
Maximum linear speed	425ft/min	130m/min
Power connection	220V, 3PH, 60AMP, 60 HZ	400V, 3PH, 60AMP, 50 HZ
Compressed air connection	90 PSI	.7 mPa
